Technical Specification | ||||
 |  |  |  | |
MODEL | 15PBG-9-N | 15PBG-10-N | 20PBG-12-N | 20PBG-15-N |
Power | 120 | 150 | 250 | 320 |
Dia(mm) | 15(1/2") | 15(1/2") | 20(3/4") | 20(3/4") |
Head(m) | 2800 | 2800 | 2800 | 2800 |
Cable(m) | 9 | 10 | 12 | 15 |
IP Geade | 40 | 45 | 65 | 75 |
Loading q'ty(pcs) | 8 | 8 | 4 | 4 |
Package Dimension(cm) | 40.5x36.5x31 | 40.5x36.5x31 | 40.5x36.5x31 | 40.5x36.5x31 |
Technical Specification | |||
 |  |  | |
MODEL | Max.power(W) | Rated power(W) | Min.power(W) |
20PBG-15-N | 320 | 250 | 150 |
Flow(L/min) | 75 | 65 | 40 |
Head(m) | 15 | 11 | 7 |
Dia(mm) | 20(3/4") | 20(3/4") | 20(3/4") |
Diameter(mm) | 76 | 100 | 100 |
Weight(kg) | 24 | 24 | 24 |
Loading q′ty(pcs) | 4 | 4 | 4 |
